Pure sine wave
DC Start & Automatic Self-Diagnostic Function
MPPT Efficiency max 98%
High efficiency design for optimized battery performance
Selectable charging current based on applications
lead acid battery/Lithium battery support
AC start-up voltage auto restart voltage/110V/120V Output Available
BMS function for lithium battery (NXT-1600L)
Can support WIFI/GPRS (NXT-1600L)
| MODEL | NXT-1600L | |
| AC Input voltage | 220VAC(standard) | |
| Input voltage range | 154-264VAC±3V(Nor Model) 185-264VAC±3V(UPS model) 175-285VAC±3V(AVR Type) |
|
| Input frequecncy | 50/60Hz±5% | |
| Out put power | 1600W | |
| Battery model output voltage | 220VAC±10% | |
| Battery model output frequency | 50 HZ or 60 HZ±1% | |
| Battery model output wave | Pure sine wave | |
| Battery type | External lead-acid battery, Gel battery, water battery or Lithium battery | |
| Battery Voltage | 24VDC | |
| Battery charging voltage | 27VDC | |
| Maximum PV array power | 1600W | |
| Solar input voltage range | 24V; MPPT 30V-150VDC | |
| Maximum PV Display Open Circuit Voltage | 150VDC | |
| Maximum solar charging current | 60A | |
| Maximum AC Charge Current | 60/30A | |
| Battery charging voltage range | 154-280VAC | |
| Transfer time | ≤10ms(UPS)/≤20ms(INV) | |
| load peak ratio | (MAX)3:1 | |
| Operating temperature | 0°C~40°C | |
| Storage temperature | -15°C~45°C | |
| Relative temperature | -10°C~90°C condensation | |
| Noise | <45dB | |
| L*W*H(mm) | 310*465*135mm | |
