| Model | SUN-30K-SG01HP3-EU-BM4 | SUN-50K-SG01HP3-EU-BM4 |
| Battery Type | Lithium-ion | |
| Battery Voltage Range (V) | 160~800 | |
| Max. Charging Current (A) | 50+50 | |
| Max. Discharging Current (A) | 50+50 | |
| Number of Battery Input | 2 | |
| Charging Strategy for Li-ion Battery | Self-adaption to BMS | |
| PV String Input Data | ||
| Max. DC Input Power (W) | 39000 | 65000 |
| Max. DC Input Voltage (V) | 1000 | |
| Start-up Voltage (V) | 180 | |
| MPPT Range (V) | 150~850 | |
| Full Load DC Voltage Range (V) | 360~850 | 450~850 |
| Rated DC Input Voltage (V) | 600 | |
| PV Input Current (A) | 36+36+36 | 36+36+36+36 |
| Max PV Isc (A) | 55+55+55 | 55+55+55+55 |
| No. of MPP Trackers | 3 | 4 |
| No. of Strings per MPP Trackers | 2+2+2 | 2+2+2+2 |
| AC Output Data | ||
| Rated AC Output and UPS Power (W) | 30000 | 50000 |
| Max. AC Output Rated Current (A) | 33000 | 55000 |
| AC Output Rated Current (A) | 45.5 / 43.5 | 75.8 / 72.5 |
| Max. AC Output Current (A) | 50 / 47.8 | 83.4 / 79.7 |
| Max. Three-phase Unbalanced Output Current(A) | 60 | 83.3 |
| Max. Continuous AC Passthrough (A) | 200 | |
| Peak Power (off grid) | 1.5 time of rated power, 10s | |
| /AC Couple Current (A) | 45.5 / 200 /45.5 | 75.8 / 200 /75.8 |
| Power Factor | 0.8 leading to 0.8 lagging | |
| Output Frequency and Voltage | 50/60Hz; 3L/N/PE 220/380, 230/400Vac | |
| Grid Type | Three Phase | |
| Total Harmonic Current Distortion (THDi) | <3% (of nominal power) | |
| DC Current Injection | <0.5% In | |
| Efficiency | ||
| Max. Efficiency | 0.976 | |
| Euro Efficiency | 0.97 | |
| MPPT Efficiency | 0.999 | |
| Protection | ||
| Integrated | Anti-islanding Protection, PV String Input Reverse Polarity Protection, Insulation Resistor Detection, Residual Current Monitoring Unit, Output Over Current Protection, Output Shorted Protection, Surge Protection, Arc Fault Circuit Interruption (AFCI optional) |
|
| Over Voltage Category | DC Type II/AC Type III | |
| Certifications and Standards | ||
| Grid Regulation | IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002, OVE-Richtlinie R25, G99, VDE-AR-N 4105 IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2 |
|
| Safety EMC / Standard | ||
| General Data | ||
| Operation Temperature Range (°C) | -40-60°C, >45°C Derating | |
| Cooling | Smart Cooling | |
| Noise (dB) | ≤65 dB | |
| Communication with BMS | CAN | |
| Weight (kg) | 80 | |
| Cabinet Size (WxHxD mm) | 527x894x294 (Excluding Connectors and Brackets) | |
| Protection Degree | IP65 | |
| Installation Style | Wall-mounted | |
| Warranty | 3 Years(parts+service free) + 2 Years (service free) | |
